Tractor · 2009Unverified
LS J2030H
LS J2030H — J Series · 27 hp. Reference specifications; pending source verification.
The LS J2030H is a tractor with a rated power of 27 hp, positioning it at the lighter end of its class. Built in 2009, it features a 3-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a hydrostatic transmission. The tractor has an operating weight of 719 kg and is designed for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
719 kg
Catalogue coverage
Variants represented
2
Richest spec table
66 rows
Recorded power
27 hp
Recorded weight
719 kg
Transmissions
hydrostatic
Production years
2009-2009
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Mitsibishi 1.3L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine (gross)20.1 kWReference
Mitsibishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power (gross)20.1 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)15.3 kWReference
Pump flow22.3 lpmReference
Total flow32.6 lpmReference
Steering flow10.2 lpmReference
Rear TypeIReference
Rear lift650 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependent (optional)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase149 cmReference
Weight719 kgReference
Weight204 kgReference
Lawn/turf front23x8.5-12Reference
Lawn/turf rear33x12-16.5Reference
Industrial front23x8.5-12Reference
Industrial rear33x12-16.5Reference
Length261 cmReference
Width114 cmReference
Height (ROPS)215 cmReference
LS J2030H attachments
60" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount LS LM3560Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width187 cmReference
Cut height2 to 10 cmReference
LS LB1104 Backhoe
Backhoe typeLS LB1104 BackhoeReference
Digging depth201 cmReference
Reach from pivot287 cmReference
Loading height144 cmReference
Bucket Rotation163°Reference
Swing Arc150°Reference
Bucket force950 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
