Tractor · Unverified
LS KR60
LS KR60 — KR SeriesCompact Utility tractor · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
1705 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
ROPS.Reference
Engine
LS 2.5L 4-cyl dieselReference
Fuel tank46.9 LReference
Engine41.8 kWReference
LS S4QLTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke88 x 103 mmReference
EmissionsTier 3Reference
Power41.8 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speed synchronized shuttleReference
32-speed power shuttleReference
Typesynchronized shuttleReference
Gears32 forward and 16 reverseReference
TransmissionEZ-shiftReference
Typepower shuttleReference
PTO & Hydraulics
PTO (claimed)33.0 kWReference
Rear valves3Reference
Pump flow29.5 lpmReference
Total flow44.3 lpmReference
Steering flow14.8 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift1250 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase175 cmReference
Weight1705 kgReference
Front tire9.5-16Reference
Rear tire13.6-24Reference
Ag front9.5-16Reference
Ag rear13.6-24Reference
Length319 cmReference
Width157 cmReference
Height (ROPS)241 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
