Tractor · Unverified

LS KR60

Name: LS KR60
Brand: LS

LS KR60 — KR SeriesCompact Utility tractor · 44 hp. Reference specifications; pending source verification.

The LS KR60 is a tractor with a power rating of 44 hp, classifying it as one of the more compact models in its category. It features a 4-cylinder turbocharged diesel liquid-cooled engine, which powers four-wheel drive via a hydrostatic transmission. The tractor has a listed weight of 1705 kg and is designed for use on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

44 hp

Weight

1705 kg

Catalogue coverage

Variants represented

Richest spec table

48 rows

Recorded power

44 hp

Recorded weight

1705 kg

Transmissions

32-speed synchronized shuttle

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference

Compact Utility tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

ROPS.Reference

Engine

LS 2.5L 4-cyl dieselReference

Fuel tank46.9 LReference

Engine41.8 kWReference

LS S4QLTReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke88 x 103 mmReference

EmissionsTier 3Reference

Power41.8 kWReference

Fuel systemindirect injectionReference

Air cleanerdryReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

32-speed synchronized shuttleReference

32-speed power shuttleReference

Typesynchronized shuttleReference

Gears32 forward and 16 reverseReference

TransmissionEZ-shiftReference

Typepower shuttleReference

PTO & Hydraulics

PTO (claimed)33.0 kWReference

Rear valves3Reference

Pump flow29.5 lpmReference

Total flow44.3 lpmReference

Steering flow14.8 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift1250 kgReference

Rear PTOindependentReference

Rear PTO Type540/750/1000Reference

Dimensions

Wheelbase175 cmReference

Weight1705 kgReference

Front tire9.5-16Reference

Rear tire13.6-24Reference

Ag front9.5-16Reference

Ag rear13.6-24Reference

Length319 cmReference

Width157 cmReference

Height (ROPS)241 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
