LS LT280D
LS LT280D · 26 hp. Reference specifications; pending source verification.
The LS LT280D is a tractor model rated at 26 hp — making it one of the more compact options in its class. Power comes from a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 12-speed gearbox. Listed weight is 1549 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1549 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
26 hp
Recorded weight
1549 kg
Transmissions
12-speed mechanical shuttle
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLSReference
Built in KoreaReference
The LT280D was sold in the US as the Farmtrac 300DTC.Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Engine
Mitsubishi 1.5L 4-cyl dieselReference
Fuel tank37.9 LReference
Engine20.9 kWReference
Mitsubishi S4LReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke78 x 79 mmReference
Power20.9 kWReference
Air cleanerDry dual elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
PTO & Hydraulics
PTO (claimed)19.7 kWReference
Valves2Reference
Total flow29.5 lpmReference
Rear TypeIReference
Rear lift1349 kgReference
Rear PTOtransmissionReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase160 cmReference
Weight1549 kgReference
Front tire8-16Reference
Rear tire12.4-24Reference
Ag front8-16Reference
Ag rear12.4-24Reference
Length330 cmReference
Width132 cmReference
Height222 cmReference
Ground clearance33 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
