Tractor · Unverified
LS LT360
LS LT360 · 28 hp. Reference specifications; pending source verification.
The LS LT360 is a tractor with a rated output of 28 hp — making it one of the more compact options in its class. Under the hood is a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 1549 kg, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1549 kg
Catalogue coverage
Variants represented
2
Richest spec table
47 rows
Recorded power
28 hp
Recorded weight
1549 kg
Transmissions
12-speed mechanical shuttle
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLSReference
Built in KoreaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Variants
LT360HSTHydrostaticReference
LT360Dshuttle transmissionReference
Engine
Mitsubishi 1.8L 4-cyl dieselReference
Fuel tank37.9 LReference
Engine28.3 kWReference
Mitsubishi S4L2Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke78 x 92 mmReference
Power28.3 kWReference
Air cleanerDry dual element/Oil bathReference
Rated RPM2700Reference
Transmission
12-speed mechanical shuttleReference
hydrostaticReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Hydro PTO (claimed)20.6 kWReference
Gear PTO (claimed)25.4 kWReference
Valves2Reference
Total flow37.9 lpmReference
Rear TypeIReference
Rear lift1349 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase160 cmReference
Weight1549 kgReference
Front tire8-16Reference
Rear tire12.4-24Reference
Ag front8-16Reference
Ag rear12.4-24Reference
Length330 cmReference
Width132 cmReference
Height222 cmReference
Ground clearance33 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
