Tractor · 2024Unverified
LS MT226E
LS MT226E — MT2E Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2963 to 3007 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
MT226EROPS shuttleReference
MT226EDROPS shuttle with transmission PTOReference
MT226HEROPS hydrostaticReference
MT226HECCab hydrostaticReference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine (gross)18.3 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power (gross)18.3 kWReference
Fuel systemindirect injectionReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchro shuttleReference
hydrostaticReference
Typesynchro shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Shuttle PTO (claimed)14.3 kWReference
Hydro PTO (claimed)12.8 kWReference
Typeopen centerReference
Shuttle Pump flow29.9 lpmReference
Hydro Pump flow26.9 lpmReference
Shuttle Total flow47.3 lpmReference
Hydro Total flow44.3 lpmReference
Steering flow17.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)650 kgReference
Rear PTOindependentReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase167 cmReference
Weight2963 to 3007 poundsReference
Front tire7-14Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference
Lawn/turf front25x8.50-14Reference
Lawn/turf rear41x14.00-20Reference
Industrial front27x8.50-15Reference
Industrial rear43x16.00-20Reference
Length302 cmReference
Width167 cmReference
Height (ROPS)241 cmReference
MT226ED1344 kgReference
Shuttle1353 kgReference
Hydro1363 kgReference
LS MT226E attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Batteries12Reference
Battery volts1Reference
Attachment overview
Front-end loaderReference
BackhoeReference
LS LB3001 Backhoe
Backhoe typeLS LB3001 BackhoeReference
Transport height207 cmReference
Digging depth246 cmReference
Reach from pivot323 cmReference
Loading height193 cmReference
Bucket Rotation180°Reference
Swing Arc160°Reference
Bucket force1661 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
