Tractor · 2024Unverified

LS MT232H

LS MT232H — MT2 Series · 32 hp. Reference specifications; pending source verification.

The LS MT232H is a tractor with a rated power output of 32 hp, categorising it at the lighter end of its class. Manufactured in 2024, it features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with hydrostatic transmission. The tractor's operating weight ranges from 3254 to 3721 pounds. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
32 hp
Weight
3254 to 3721 pounds

Catalogue coverage

Variants represented
2
Richest spec table
71 rows
Recorded power
32 hp
Recorded weight
1476 kg
Transmissions
hydrostatic
Production years
2024-2024
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab available with air-conditioning.Reference

Variants

MT232EEconomy ROPS shuttleReference
MT232HEEconomy ROPS hydrostaticReference
MT232HECEconomy cab hydrostaticReference
MT232HDeluxe ROPS hydrostaticReference
MT232HCdeluxe cab hydrostaticReference

Engine

Yanmar 1.6L 3-cyl dieselReference
Fuel tank40.1 LReference
ROPS Fuel tank-unknown-Reference
Cab Fuel tank43.1 LReference
Engine (gross)23.6 kWReference
Yanmar 3TNV88CReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.6 LReference
Bore/Stroke88 x 90 mmReference
Power (gross)23.6 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference

Transmission

hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)19.5 kWReference
Typeopen centerReference
Pump flow25.4 lpmReference
Total flow44.3 lpmReference
Steering flow18.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)650 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase175 cmReference
Weight3254 to 3721 poundsReference
Front tire7-14Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference
Lawn/turf front25x8.50-14Reference
Lawn/turf rear41x14.00-20Reference
Industrial front27x8.50-15Reference
Industrial rear43x16.00-20Reference
Length317 cmReference
Width167 cmReference
Height (ROPS)241 cmReference
Height (cab)228 cmReference
ROPS Weight1476 kgReference
Cab Weight1687 kgReference

LS MT232H attachments

front-end loaderReference
backhoeReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Batteries12Reference
Battery volts1Reference

Attachment overview

Front-end loaderReference
BackhoeReference

LS LB3002 Backhoe

Backhoe typeLS LB3002 BackhoeReference
Transport height207 cmReference
Digging depth246 cmReference
Reach from pivot323 cmReference
Loading height193 cmReference
Bucket Rotation180°Reference
Swing Arc160°Reference
Bucket force1661 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
