Tractor · 2019Unverified
LS MT235E
LS MT235E — MT2E Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2866 to 2870 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
MT235HEhydrostaticReference
Engine
LS 1.9L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine (gross)26.1 kWReference
LS L3C19-D2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke88 x 103 mmReference
EmissionsTier IVReference
Power (gross)26.1 kWReference
Fuel systemcommon rail direct injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchro shuttleReference
hydrostaticReference
Typesynchro shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Shuttle PTO (claimed)22.1 kWReference
Valves0 to 2Reference
Pump flow31.0 lpmReference
Shuttle Total flow46.6 lpmReference
Hydro Total flow51.9 lpmReference
Shuttle Steering flow15.5 lpmReference
Hydro Steering flow20.8 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)820 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase175 cmReference
Weight2866 to 2870 poundsReference
Front tire7-14Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference
Lawn/turf front25x8.5-14Reference
Lawn/turf rear41x14-20Reference
Industrial front25x8.5-14Reference
Industrial rear43x16-20Reference
Length307 cmReference
Width137 cmReference
Height (ROPS)223 cmReference
Shuttle Weight1300 kgReference
Hydro Weight1301 kgReference
LS MT235E attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
LS LB1105 Backhoe
Backhoe typeLS LB1105 BackhoeReference
Transport height196 cmReference
Digging depth193 cmReference
Reach from pivot287 cmReference
Loading height161 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1277 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
