Tractor · 2020Unverified
LS MT357
LS MT357 — MT3 Series · 57 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
57 hp
Weight
1754 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
LS Mtron 1.9L 3-cyl dieselReference
ROPS Fuel tank40.1 LReference
Cab Fuel tank46.9 LReference
Engine (gross)42.5 kWReference
LS Mtron L3C19-T7Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.9 LReference
Bore/Stroke88 x 103 mmReference
EmissionsTier IVReference
Power (gross)42.5 kWReference
Fuel systemcommon rail direct injectionReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2600Reference
Idle RPM950-2750Reference
Torque188.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity5.9 LReference
Transmission
16-speed synchro shuttleReference
hydrostaticReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)34.0 kWReference
Shuttle PTO (claimed)36.1 kWReference
Typeopen centerReference
Pressure170.0 barReference
Valves3Reference
Pump flow31.0 lpmReference
ROPS shuttle Total flow46.6 lpmReference
ROPS hydro Total flow54.1 lpmReference
Cab hydro Total flow56.8 lpmReference
ROPS shuttle Steering flow15.5 lpmReference
ROPS hydro Steering flow20.8 lpmReference
Cab hydro Steering flow25.7 lpmReference
Steering press.142.2 barReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)1249 kgReference
Rear lift (at 24"/610mm)1119 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2409Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Engine RPM2000@2562Reference
Dimensions
Wheelbase185 cmReference
Weight1754 kgReference
Front tire9.5-16Reference
Rear tire13.6-24Reference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-24Reference
Lawn/turf front28x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front12-16.5Reference
Industrial rear17.5L-24Reference
Length362 cmReference
Width161 cmReference
Height (ROPS)243 cmReference
Height (cab)230 cmReference
LS MT357 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
LS LB2105 Backhoe
Backhoe typeLS LB2105 BackhoeReference
Transport height212 cmReference
Digging depth227 cmReference
Reach from pivot318 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1215 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
