LS Neo N47
LS Neo N47 — Compact Utility tractor · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
4321 to 5203 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Built in KoreaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPs. Cab optional.Reference
Engine
Mitsubishi 2.5L 4-cyl dieselReference
ROPS Fuel tank60.2 LReference
Cab Fuel tank50.7 LReference
Engine36.5 kWReference
Mitsubishi S4QLReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke88 x 103 mmReference
Power36.5 kWReference
Air cleanerdry dual elementReference
Rated RPM2600Reference
Transmission
8-speedReference
16-speedReference
Transmissionsynchro shuttleReference
Gears8 forward and reverseReference
Gears16 forward and reverseReference
PTO & Hydraulics
Valves2Reference
Total flow31.8 lpmReference
Rear TypeIReference
Rear lift1450 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Mid PTOoptionalReference
Dimensions
Wheelbase189 cmReference
Weight4321 to 5203 poundsReference
Front tire9.5-20Reference
Rear tire13.6-28Reference
Ag front9.5-20Reference
Ag rear13.6-28Reference
Length319 cmReference
Width133 cmReference
Height243 cmReference
Cab Weight2360 kgReference
ROPS Weight1960 kgReference
Ground clearance36 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
