Tractor · 2009Unverified
LS P7040
LS P7040 — P Series · 97 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
97 hp
Weight
6660 to 7143 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS. Cab available with air-conditioning.Reference
Variants
P7040FROPSReference
P7040CPScab with power shuttleReference
Engine
Iveco FPT 4.5L 4-cyl dieselReference
Fuel tank99.9 LReference
Engine (gross)72.3 kWReference
Iveco FPT NEFReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
EmissionsInterim Tier 4Reference
Power (gross)72.3 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speed synchro shuttleReference
40-speed power shuttleReference
Typesynchro shuttleReference
Gears20 forward and reverseReference
Typepower shuttleReference
Gears40 forward and 20 reverseReference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
Rear valves3Reference
Pump flow60.2 lpmReference
Total flow86.7 lpmReference
Steering flow26.5 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2800 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase228 cmReference
Weight6660 to 7143 poundsReference
Front tire12.4-24Reference
Rear tire18.4-30 (ROPS)Reference
Standard tires (ag)Front: 12.4-24. Rear: 18.4-30 (ROPS)Reference
Standard tires (ag)Front: 13.6-24. Rear: 18.4-34 (Cab)Reference
Length407 cmReference
Width199 cmReference
Height (ROPS)266 cmReference
Height (cab)259 cmReference
Weight3020 kgReference
Weight3240 kgReference
LS P7040 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
