Tractor · Unverified

LS PS70

Name: LS PS70
Brand: LS

LS PS70 — PLUS SeriesUtility tractor · 63 hp. Reference specifications; pending source verification.

The LS PS70 is a tractor with a rated power of 63 hp, categorising it at the lighter end of its class. It is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The tractor's operating weight is listed as 6363 to 6887 pounds. It is suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

63 hp

Weight

6363 to 6887 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

63 hp

Recorded weight

2886 kg

Transmissions

12-speed synchronized shuttle

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference

Utility tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

ROPS. Cab optional with air-conditioning.Reference

Engine

FPT 3.2L 4-cyl dieselReference

Fuel tank99.9 LReference

Engine52.9 kWReference

FPT F5CReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.2 LReference

Bore/Stroke99 x 104 mmReference

EmissionsTier 3Reference

Power52.9 kWReference

Air cleanerdryReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronized shuttleReference

20-speed synchronized shuttleReference

40-speed power shuttleReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Gears20 forward and reverseReference

Typepower shuttleReference

Gears40 forward and reverseReference

PTO & Hydraulics

PTO (claimed)47.0 kWReference

Rear valves3Reference

Front valves2Reference

ROPS Pump flow40.9 lpmReference

Cab Pump flow56.0 lpmReference

Steering flow22.7 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift2800 kgReference

Rear PTOindependentReference

Rear PTO Type540/750/1000Reference

Dimensions

Wheelbase219 cmReference

Weight6363 to 6887 poundsReference

Front tire11.2-24Reference

Rear tire16.9-30Reference

Ag front11.2-24Reference

Ag rear16.9-30Reference

Length399 cmReference

Width197 cmReference

Height (ROPS)265 cmReference

Height (cab)259 cmReference

ROPS Weight2886 kgReference

Cab Weight3123 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
