Tractor · 2009Unverified

LS R4020H

Name: LS R4020H
Brand: LS

LS R4020H — R Series · 47 hp. Reference specifications; pending source verification.

The LS R4020H is a compact tractor with a rating of 47 hp, manufactured between 2009 and 2010. It features a 4-cylinder diesel liquid-cooled engine, which drives a four-wheel drive system via a hydrostatic transmission. The tractor's listed weight is 1729 kg. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

1729 kg

Catalogue coverage

Variants represented

Richest spec table

71 rows

Recorded power

47 hp

Recorded weight

1729 kg

Transmissions

hydrostatic

Production years

2009-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference

Compact Utility tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

R4020shuttleReference

R4020HhydrostaticReference

Engine

Mitsubishi 2.5L 4-cyl dieselReference

Fuel tank36.0 LReference

Engine (gross)35.0 kWReference

Mitsubishi S4QLReference

indirect injection dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke88 x 103 mmReference

Power (gross)35.0 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)30.6 kWReference

Pump flow31.0 lpmReference

Total flow46.6 lpmReference

Steering flow15.5 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift1249 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase175 cmReference

Weight1729 kgReference

Front tire9.5x16Reference

Rear tire12.4x24Reference

Weight257 kgReference

Standard tires (ag)Front: 9.5x16. Rear: 12.4x24Reference

Lawn/turf front28x8.5-15Reference

Lawn/turf rear41x14-20Reference

Industrial front10x16.5Reference

Industrial rear43x14-20.4Reference

Length335 cmReference

Width141 cmReference

Height (ROPS)241 cmReference

LS R4020H attachments

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery volts12Reference

Attachment overview

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

72" Mower deck

Typemid-mount LM4500Reference

Type3-bladeReference

Cutting width182 cmReference

Overall width218 cmReference

Cut height2 to 10 cmReference

LS LB2101 Backhoe

Backhoe typeLS LB2101 BackhoeReference

Digging depth227 cmReference

Reach from pivot317 cmReference

Loading height183 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1277 kgReference

Dipperstick force954 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
