Tractor · 2011Unverified

LS R4047EZ

LS R4047EZ — R Series · 47 hp. Reference specifications; pending source verification.

The LS R4047EZ is a tractor with an approximate power rating of 47 hp, categorising it at the lower end of its class. It was manufactured in 2011. The tractor is equipped with a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its listed operating weight is 1729 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
47 hp
Weight
1729 kg

Catalogue coverage

Variants represented
2
Richest spec table
62 rows
Recorded power
47 hp
Recorded weight
1729 kg
Transmissions
16-speed synchro shuttle
Production years
2011-2011
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference

Engine

Mitsibishi 2.5L 4-cyl dieselReference
Fuel tank36.0 LReference
Engine (gross)35.0 kWReference
Mitsibishi S4QLReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke88 x 103 mmReference
Power (gross)35.0 kWReference
Fuel systemindirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference

Transmission

16-speed synchro shuttleReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
EZ Shift adds a push-button clutch in addition to the foot clutch.Reference

PTO & Hydraulics

PTO (claimed)30.6 kWReference
Pump flow31.0 lpmReference
Total flow46.6 lpmReference
Steering flow15.5 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift1249 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependent (optional)Reference
Mid PTO Type2000Reference

Dimensions

Wheelbase175 cmReference
Weight1729 kgReference
Front tire9.5-16Reference
Rear tire13.6-24Reference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-24Reference
Lawn/turf front28x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front12x16.5Reference
Industrial rear17.5L-24Reference
Length335 cmReference
Width141 cmReference
Height (ROPS)241 cmReference

LS R4047EZ attachments

front-end loaderReference
backhoeReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference

Attachment overview

Front-end loaderReference
BackhoeReference

LS LB2101 Backhoe

Backhoe typeLS LB2101 BackhoeReference
Digging depth227 cmReference
Reach from pivot317 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1215 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
