Tractor · 2011Unverified

LS R4047H

Name: LS R4047H
Brand: LS

LS R4047H — R Series · 47 hp. Reference specifications; pending source verification.

The LS R4047H is a tractor model with an approximate engine rating of 47 hp, categorising it as a lighter tractor in its class. Manufactured in 2011, the R4047H is equipped with a 4-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a hydrostatic transmission. It has an operating weight of 1729 kg, and is suitable for operations up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

1729 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

47 hp

Recorded weight

1729 kg

Transmissions

hydrostatic

Production years

2011-2011

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference

Compact Utility tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Engine

Mitsibishi 2.5L 4-cyl dieselReference

Fuel tank36.0 LReference

Engine (gross)35.0 kWReference

Mitsibishi S4QLReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke88 x 103 mmReference

Power (gross)35.0 kWReference

Fuel systemindirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)28.3 kWReference

Pump flow31.0 lpmReference

Total flow51.9 lpmReference

Steering flow20.8 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift1249 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependent (optional)Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase175 cmReference

Weight1729 kgReference

Front tire9.5-16Reference

Rear tire13.6-24Reference

Standard tires (ag)Front: 9.5-16. Rear: 13.6-24Reference

Lawn/turf front28x8.5-15Reference

Lawn/turf rear41x14-20Reference

Industrial front12x16.5Reference

Industrial rear17.5L-24Reference

Length335 cmReference

Width141 cmReference

Height (ROPS)241 cmReference

LS R4047H attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

LS LB2101 Backhoe

Backhoe typeLS LB2101 BackhoeReference

Digging depth227 cmReference

Reach from pivot317 cmReference

Loading height183 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1215 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
