Tractor · Unverified
LS Rio R28
LS Rio R28 · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1200 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
ROPSReference
Engine
Mitsubishi 1.5L 4-cyl dieselReference
Fuel tank32.2 LReference
Engine20.9 kWReference
Mitsubishi S4LReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke78 x 79 mmReference
Power20.9 kWReference
Air cleanerDry Dual ElementReference
Rated RPM2600Reference
Transmission
12-speedReference
Transmissionsynchro shuttleReference
Gears12 forward and reverseReference
PTO & Hydraulics
Valves0 to 2Reference
Pump flow29.9 lpmReference
Steering flow12.9 lpmReference
Rear TypeIReference
Rear lift1187 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Dimensions
Wheelbase166 cmReference
Weight1200 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Length298 cmReference
Height231 cmReference
Ground clearance33 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
