Tractor · Unverified
LS Rio R41
LS Rio R41 · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
1625 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
ROPSReference
Engine
Mitsubishi 2.3L 4-cyl dieselReference
Fuel tank40.1 LReference
Engine30.6 kWReference
Mitsubishi S4QSReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke88 x 95 mmReference
Power30.6 kWReference
Air cleanerDry Dual ElementReference
Rated RPM2600Reference
Transmission
16-speedReference
Transmissionsynchro shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
Valves2Reference
Pump flow31.0 lpmReference
Steering flow15.5 lpmReference
Rear TypeIReference
Rear lift1250 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Mid PTOoptionalReference
Dimensions
Wheelbase175 cmReference
Weight1625 kgReference
Front tire8-16Reference
Rear tire12.4-24Reference
Ag front8-16Reference
Ag rear12.4-24Reference
Length319 cmReference
Height241 cmReference
Ground clearance35 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
