Tractor · Unverified
LS Topa 27
LS Topa 27 · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1295 kg
Hover a source tag to verify
Overview
ManufacturerLSReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Daedong 1.4L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine20.1 kWReference
Daedong 3A139Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke80 x 92 mmReference
Power20.1 kWReference
Air cleanerDry dual elementReference
Rated RPM2600Reference
Transmission
8-speedReference
Transmissionsynchro shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)17.7 kWReference
Valves0 or 1Reference
Pump flow22.0 lpmReference
Steering flow12.9 lpmReference
Rear TypeIReference
Rear lift723 kgReference
Rear PTOtransmissionReference
Rear PTOlive optionalReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase167 cmReference
Weight1295 kgReference
Front tire6-14Reference
Rear tire9.5-24Reference
Ag front6-14Reference
Ag rear9.5-24Reference
Length293 cmReference
Width126 cmReference
Ground clearance29 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
