Tractor · Unverified
LS Topa 32
LS Topa 32 · 29 hp. Reference specifications; pending source verification.
The LS Topa 32 is a tractor with a rated power of 29 hp, categorised as a lighter model within its class. It features a 3-cylinder diesel liquid-cooled engine, combined with four-wheel drive and a hydrostatic transmission. The tractor's operating weight is 1295 kg, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1295 kg
Catalogue coverage
Variants represented
2
Richest spec table
42 rows
Recorded power
29 hp
Recorded weight
1295 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerLSReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Daedong 1.6L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine23.9 kWReference
Daedong 3A165Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power23.9 kWReference
Air cleanerDry dual elementReference
Rated RPM2600Reference
Transmission
8-speedReference
Transmissionsynchro shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)21.3 kWReference
Valves0 or 1Reference
Pump flow22.0 lpmReference
Steering flow12.9 lpmReference
Rear TypeIReference
Rear lift723 kgReference
Rear PTOtransmissionReference
Rear PTOlive optionalReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase167 cmReference
Weight1295 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Length293 cmReference
Width132 cmReference
Ground clearance31 cmReference
Electrical
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
