Tractor · Unverified
LS U6030
LS U6030 — U SeriesUtility tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
4773 to 5225 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
ROPS. Cab optional.Reference
Engine
LS 2.6L 4-cyl dieselReference
Fuel tank79.9 LReference
Engine46.2 kWReference
LS L4AL-T1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
EmissionsTier 3Reference
Power46.2 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)40.6 kWReference
Rear valves2Reference
Front valves2Reference
Pump flow34.4 lpmReference
Total flow52.2 lpmReference
Steering flow17.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase204 cmReference
Weight4773 to 5225 poundsReference
Front tire11.2-20Reference
Rear tire14.9-28Reference
Ag front11.2-20Reference
Ag rear14.9-28Reference
Length343 cmReference
Width177 cmReference
Height (ROPS)261 cmReference
Height (cab)250 cmReference
ROPS Weight2165 kgReference
Cab Weight2370 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
