Tractor · 2016Unverified

LS XG3135

Name: LS XG3135
Brand: LS

LS XG3135 — XG Series · 35 hp. Reference specifications; pending source verification.

The LS XG3135 is a tractor with a rated output of 35 hp, categorising it as one of the more compact options in its class. It was manufactured between 2016 and 2019. The tractor features a 3-cylinder turbocharged diesel liquid-cooled engine, driving through four-wheel drive via a hydrostatic transmission. It has a listed weight of 1308 kg and is suited to jobs involving approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

35 hp

Weight

1308 kg

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

35 hp

Recorded weight

1308 kg

Transmissions

12-speed sync shuttle

Production years

2016-2019

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

LS 1.9L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine (gross)26.1 kWReference

LS L3C19-TReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke88 x 103 mmReference

Power (gross)26.1 kWReference

Compression17:1Reference

Rated RPM2600Reference

Torque119.1 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed sync shuttleReference

hydrostaticReference

Typesync shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

Four gears in three ranges with left-hand shuttle lever. Tractor must be stopped, and clutch used, to shift gears or range.Reference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)22.4 kWReference

Hydro PTO (claimed)20.9 kWReference

Typeopen centerReference

Pump flow31.0 lpmReference

Gear Total flow46.6 lpmReference

Hydro Total flow51.9 lpmReference

Gear Steering flow15.5 lpmReference

Hydro Steering flow20.8 lpmReference

Rear TypeIReference

Rear lift (at ends)820 kgReference

Rear lift (at 24"/610mm)650 kgReference

Rear PTOindependentReference

Clutchwet discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2509Reference

Dimensions

Wheelbase175 cmReference

Weight1308 kgReference

Front tire7-14Reference

Rear tire11.2-24Reference

Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference

Lawn/turf front25x8.5-14Reference

Lawn/turf rear41x14-20Reference

Industrial front25x8.5-14Reference

Industrial rear43x16-20Reference

Length307 cmReference

Width137 cmReference

Height (ROPS)223 cmReference

Front tread111 to 120 cmReference

Rear tread109 to 132 cmReference

LS XG3135 attachments

front-end loaderReference

backhoeReference

Electrical

Charging amps70Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

LS LB1105 Backhoe

Backhoe typeLS LB1105 BackhoeReference

Transport height196 cmReference

Digging depth193 cmReference

Reach from pivot287 cmReference

Loading height161 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1277 kgReference

Speeds

With 11.2-24 R1 rear tires. Reverse speeds are 5% slower than forward.Reference

With 11.2-24 R1 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
