Tractor · Unverified
LS XJ2025
LS XJ2025 — XJ SeriesCompact Utility tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1609 to 1785 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
XJ2025gearReference
XJ2025HhydrostaticReference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine (gross)18.2 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
EmissionsTier IVReference
Power (gross)18.2 kWReference
Fuel systemindirect injectionReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
Gear Weight809 kgReference
TypegearReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Gear PTO (claimed)14.5 kWReference
Hydro PTO (claimed)13.8 kWReference
Gear Pump flow26.1 lpmReference
Hydro Pump flow22.3 lpmReference
Gear Total flow30.3 lpmReference
Hydro Total flow32.2 lpmReference
Gear Steering flow4.2 lpmReference
Hydro Steering flow9.8 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)650 kgReference
Rear PTOindependentReference
ClutchindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM2000Reference
Dimensions
Wheelbase149 cmReference
Weight1609 to 1785 poundsReference
Weight204 kgReference
Lawn/turf front23x8.5-12Reference
Lawn/turf rear33x12.5-16.5Reference
Industrial front23x8.5-12Reference
Industrial rear33x12-16.5Reference
Length261 cmReference
Width114 cmReference
Height (ROPS)234 cmReference
Hydro Weight729 kgReference
LS XJ2025 attachments
60" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount LS LM3560Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width187 cmReference
Cut height2 to 10 cmReference
LS LB1104 Backhoe
Backhoe typeLS LB1104 BackhoeReference
Transport height191 cmReference
Digging depth201 cmReference
Reach from pivot287 cmReference
Loading height144 cmReference
Bucket Rotation163°Reference
Swing Arc150°Reference
Bucket force950 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
