Tractor · 2013Unverified

LS XR3037

Name: LS XR3037
Brand: LS

LS XR3037 — XR Series · 36 hp. Reference specifications; pending source verification.

The LS XR3037 is a compact tractor model rated at 36 hp. Manufactured from 2013 to 2018, it is powered by a 3-cylinder turbocharged diesel liquid-cooled engine, which drives a four-wheel drive system via a hydrostatic transmission. The tractor weighs 1460 kg and is suitable for jobs involving approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

36 hp

Weight

1460 kg

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

36 hp

Recorded weight

1460 kg

Transmissions

12-speed synchro shuttle

Production years

2013-2018

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference

Compact Utility tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Engine

Shibarua 1.5L 3-cyl dieselReference

Fuel tank39.7 LReference

Fuel tank46.9 LReference

Engine (gross)27.0 kWReference

Shibarua N843T-FReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke84 x 90 mmReference

EmissionsTier 4Reference

Emission controlexhaust-gas recirculation (EGR)Reference

Power (gross)27.0 kWReference

Fuel systemindirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchro shuttleReference

Typesynchro shuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

PTO (claimed)22.6 kWReference

Pump flow31.0 lpmReference

Total flow46.9 lpmReference

Steering flow15.9 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift820 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependent (optional)Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase167 cmReference

Weight1460 kgReference

Front tire7-14Reference

Rear tire11.2-24Reference

Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference

Lawn/turf front25x8.5-14Reference

Lawn/turf rear41x14-20Reference

Industrial front25x8.5-14Reference

Industrial rear43x16-20Reference

Length307 cmReference

Width152 cmReference

Height (ROPS)228 cmReference

LS XR3037 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps85Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

LS LB2103 Backhoe

Backhoe typeLS LB2103 BackhoeReference

Digging depth227 cmReference

Reach from pivot317 cmReference

Loading height183 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1215 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
