Tractor · 2013Unverified

LS XU5065

LS XU5065 — XU Series · 65 hp. Reference specifications; pending source verification.

The LS XU5065 is a tractor with a rated power output of 65 hp, falling within a typical range for its class. Manufactured from 2013 to 2016, this model features a 4-cylinder turbocharged diesel liquid-cooled engine, combined with four-wheel drive and a hydrostatic transmission. Its operating weight is listed as 4674 to 5121 pounds. It is capable of handling operations covering an area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
65 hp
Weight
4674 to 5121 pounds

Catalogue coverage

Variants represented
2
Richest spec table
65 rows
Recorded power
65 hp
Recorded weight
2120 kg
Transmissions
16-speed power shuttle
Production years
2013-2016
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerLSReference
Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference

Engine

Shibarua 2.2L 4-cyl dieselReference
Fuel tank59.8 LReference
Fuel tank20.1 LReference
Engine (gross)48.5 kWReference
Shibarua N4LDI-TAReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
EmissionsTier 4Reference
Emission controlexhaust-gas recirculation (EGR)Reference
Power (gross)48.5 kWReference
Fuel systemcommon rail direct injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference

Transmission

16-speed power shuttleReference
Typepower shuttleReference
Gears16 forward and reverseReference

PTO & Hydraulics

PTO (claimed)39.8 kWReference
Pump flow39.7 lpmReference
Total flow59.8 lpmReference
Steering flow20.1 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1850 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase203 cmReference
Weight4674 to 5121 poundsReference
Front tire9.5-20Reference
Rear tire16.9-24Reference
Standard tires (ag)Front: 9.5-20. Rear: 16.9-24Reference
Lawn/turf front36x13.5-15Reference
Lawn/turf rear16.9-24Reference
Industrial front10.5/80-18Reference
Industrial rear19.5L-24Reference
Length359 cmReference
Width170 cmReference
Height (ROPS)261 cmReference
Height (cab)255 cmReference
Weight2120 kgReference
Weight2322 kgReference

LS XU5065 attachments

front-end loaderReference
backhoeReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference

Attachment overview

Front-end loaderReference
BackhoeReference

LS LB3101 Backhoe

Backhoe typeLS LB3101 BackhoeReference
Digging depth239 cmReference
Reach from pivot345 cmReference
Loading height203 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1700 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
