Tractor · 2017Unverified
LS XU6158
LS XU6158 — XU Series · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Weight
4674 to 5121 pounds
Hover a source tag to verify
Overview
ManufacturerLSReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Variants
XU6158CCabReference
Engine
LS 2.5L 4-cyl dieselReference
Fuel tank59.8 LReference
Engine (gross)43.3 kWReference
LS L4C25-TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.5 LReference
Bore/Stroke88 x 103 mmReference
EmissionsTier IVReference
Power (gross)43.3 kWReference
Rated RPM2500Reference
Torque206.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)38.2 kWReference
Typeopen centerReference
Valves2Reference
Pump flow37.5 lpmReference
Total flow54.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift1850 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase203 cmReference
Weight4674 to 5121 poundsReference
Front tire9.5-20Reference
Rear tire16.9-24Reference
Ag front9.5-20Reference
Ag rear16.9-24Reference
Lawn/turf front36x13.5-15Reference
Lawn/turf rear16.9-24Reference
Industrial front10.5/80-18Reference
Industrial rear19.5L-24Reference
Length352 cmReference
Width177 cmReference
Height (ROPS)178 cmReference
Height (cab)255 cmReference
ROPS Weight2120 kgReference
Cab Weight2322 kgReference
LS XU6158 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
LS LB3102 Backhoe
Backhoe typeLS LB3102 BackhoeReference
Transport height235 cmReference
Digging depth240 cmReference
Reach from pivot345 cmReference
Loading height203 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1696 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
