Tractor · 1966Unverified
M-R-S A-95
M-R-S A-95 — Model year 1966-19701977-1980 · 186 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
186 hp
Hover a source tag to verify
Overview
ManufacturerM-R-SReference
Four-wheel Drive (4WD) tractorReference
Built in Flora, Mississippi, USAReference
Drive4x4 4WDReference
Power four-wheel steeringReference
Open operator station. Cab optional with heater.Reference
Engine
Detroit Diesel 5.2L 6-cyl dieselReference
Fuel tank529.9 LReference
Engine138.7 kWReference
Drawbar (claimed)111.9 kWReference
Detroit Diesel 6V-53NReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.2 LReference
Bore/Stroke98 x 114 mmReference
Power138.7 kWReference
Rated RPM2500Reference
Torque585.8 NmReference
Torque RPM1500Reference
Starter typeelectricReference
Oil capacity18.0 LReference
Coolant capacity39.7 LReference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
Clutch381mm dry discReference
PTO & Hydraulics
Pump flow94.6 lpmReference
Dimensions
Wheelbase299 cmReference
Front tire23.1x26Reference
Rear tire23.1x26Reference
Ag front23.1x26Reference
Ag rear23.1x26Reference
Ag front16.00-24Reference
Ag front18.00-25Reference
Ag front18.00-26Reference
Ag rear16.00-24Reference
Ag rear18.00-25Reference
Ag rear18.00-26Reference
Length495 cmReference
Width264 cmReference
Height297 cmReference
Max weight11793 kgReference
Ground clearance41 cmReference
Front tread203 cmReference
Rear tread203 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
