Tractor · 2024Unverified

Mahindra 1126

Name: Mahindra 1126
Brand: Mahindra

Mahindra 1126 — Sub-Compact Utility tractor · 19 hp. Reference specifications; pending source verification.

The Mahindra 1126 is a compact tractor model with a rating of 19 hp, making it one of the smaller options in its class. Introduced in 2024, this tractor is equipped with a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive via a hydrostatic transmission. Weights for this model are listed as between 1620 and 1962 pounds, and it is intended for use on small to medium-sized plots of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

19 hp

Weight

1620 to 1962 pounds

Catalogue coverage

Variants represented

Richest spec table

73 rows

Recorded power

19 hp

Transmissions

hydrostatic

Production years

2024-1100

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post folding ROPS. Cab optional with heater.Reference

Engine

Mitsubishi 1.1L 3-cyl dieselReference

Fuel tank25.0 LReference

Engine18.9 kWReference

Mitsubishi MLV3E3Reference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.1 LReference

Bore/Stroke76 x 81 mmReference

Power18.9 kWReference

Fuel systemindirect injectionReference

Rated RPM3000Reference

Torque65.0 NmReference

Torque RPM2200Reference

Firing order1-3-2Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)14.3 kWReference

Typeopen centerReference

Rear valves2Reference

Pump flow28.8 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)349 kgReference

Rear PTOindependentReference

Clutchwet discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2837Reference

Mid PTOindependentReference

Engine RPM2500@2837Reference

Dimensions

Wheelbase139 cmReference

Weight1620 to 1962 poundsReference

Weight149 kgReference

Weight321 kgReference

Lawn/turf front18x8.5-10Reference

Lawn/turf rear26x12-12Reference

Industrial front18x8.5-10Reference

Industrial rear26x12-12Reference

Length255 cmReference

Width117 cmReference

Height (ROPS)219 cmReference

Height (cab)204 cmReference

ROPS Weight734 kgReference

Cab Weight889 kgReference

Ground clearance17 cmReference

Mahindra 1126 attachments

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery CCA650Reference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

60" Mower deck

Typemid-mount Mahindra M1160Reference

Type3-bladeReference

Cutting width152 cmReference

Cut height2 to 10 cmReference

Mahindra B11 Backhoe

Backhoe typeMahindra B11 BackhoeReference

Digging depth193 cmReference

2-Foot flat digging depth190 cmReference

Bucket force1045 kgReference

Dipperstick force704 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
