Tractor · 2016Unverified
Mahindra 1526
Mahindra 1526 — Compact Utility tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
2437 to 2459 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Original price$16,340 (2016 shuttle )Reference
Original price$17,480 (2016 hydrostatic )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine19.1 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
EmissionsTier IVReference
Power19.1 kWReference
Fuel systemdirect injectionReference
Compression22:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed shuttleReference
hydrostaticReference
TypeshuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Shuttle PTO (claimed)14.2 kWReference
Hydro PTO (claimed)13.8 kWReference
Typeopen centerReference
Rear valves1Reference
Pump flow28.4 lpmReference
Steering flow12.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1200 kgReference
Rear Armstelescopic stabilizersReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2000Reference
Dimensions
Weight2437 to 2459 poundsReference
Front tire7x16Reference
Rear tire11.2x24Reference
Weight381 kgReference
Standard tires (ag)Front: 7x16. Rear: 11.2x24Reference
Lawn/turf front25x8.5-14Reference
Lawn/turf rear13.6x16Reference
Industrial front27x8.5-15Reference
Industrial rear15x19.5Reference
Length308 cmReference
Width160 cmReference
Height (ROPS)207 cmReference
Shuttle Weight1105 kgReference
Hydro Weight1115 kgReference
Mahindra 1526 attachments
front-end loaderReference
backhoeReference
Electrical
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery CCA540Reference
Battery volts12Reference
Battery AH46Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 1526B Backhoe
Backhoe typeMahindra 1526B BackhoeReference
Transport height185 cmReference
Digging depth218 cmReference
2-Foot flat digging depth213 cmReference
Reach from pivot289 cmReference
Loading height172 cmReference
Bucket Rotation185°Reference
Swing Arc145°Reference
Bucket force1106 kgReference
Dipperstick force684 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
