Tractor · 2018Unverified

Mahindra 1626

Name: Mahindra 1626
Brand: Mahindra

Mahindra 1626 — Compact Utility tractor · 22 hp. Reference specifications; pending source verification.

The Mahindra 1626 is a tractor model with a rated power of 22 hp, positioning it at the lighter end of its class. It was introduced to production in 2018. Powered by a 3-cylinder diesel liquid-cooled engine, it features four-wheel drive with a hydrostatic transmission, and its operating weight is listed as 2437 to 2459 pounds. The 1626 is suited to operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

2437 to 2459 pounds

Catalogue coverage

Variants represented

Richest spec table

119 rows

Recorded power

22 hp

Recorded weight

381 kg

Transmissions

8-speed sync shuttle

Production years

2018-1600

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Compact Utility tractorReference

Original price$18,200 (2018 gear )Reference

Original price$23,890 (2018 hydro )Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Mitsubishi 1.3L 3-cyl dieselReference

Fuel tank26.9 LReference

Engine19.3 kWReference

Mitsubishi S3L2Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 92 mmReference

EmissionsTier IVReference

Power19.3 kWReference

Fuel systemindirect injectionReference

Air cleanerdryReference

Compression22:1Reference

Rated RPM2500Reference

Idle RPM970-2710Reference

StarterelectricReference

Starter volts12Reference

Intake valve clearance0.254 mmReference

Exhaust valve clearance0.254 mmReference

Fuel TypeDieselReference

No of Cylinders3 cylinderReference

Emissions complianceTier IVReference

Bore and stroke3.071x3.622 inchesReference

Compression ratio22:1Reference

Cooling systemliquid-cooledReference

Transmission

8-speed sync shuttleReference

hydrostaticReference

Gear Operating1105 kgReference

Typesync shuttleReference

Gears8 forward and reverseReference

Clutch215mm mechanical dry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeHSTReference

PTO & Hydraulics

Gear PTO (claimed)16.0 kWReference

Hydro PTO (claimed)14.2 kWReference

Typeopen centerReference

Pressure151.7 barReference

Pump flow28.4 lpmReference

Steering flow12.1 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)1200 kgReference

Rear lift (at 24"/610mm)780 kgReference

Shuttle Rear PTOliveReference

Hydro Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2376Reference

Mid PTO Type2000 (1.0)Reference

Engine RPM2000@2545Reference

Dimensions

Wheelbase170 cmReference

Weight2437 to 2459 poundsReference

Front tire7-16Reference

Rear tire11.2-24Reference

Weight381 kgReference

Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference

Lawn/turf front25x8.5-14Reference

Lawn/turf rear13.6x16Reference

Industrial front27x8.5-15Reference

Industrial rear15x19.5Reference

Length308 cmReference

Width160 cmReference

Height (ROPS)207 cmReference

Ground clearance28 cmReference

Hydro Operating1115 kgReference

Max Drawbar439 kgReference

Mahindra 1626 attachments

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery CCA540Reference

Battery volts12Reference

Total cold cranking amps540 CCAReference

Attachment overview

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

72" Mower deck

Typemid-mount MahindraReference

Cutting width182 cmReference

Mahindra 1626B Backhoe

Backhoe typeMahindra 1626B BackhoeReference

Bucket width40 cmReference

Digging depth218 cmReference

2-Foot flat digging depth213 cmReference

Bucket force1106 kgReference

Dipperstick force684 kgReference

Speeds

With 15x19.5 rear tires. Reverse speeds are 15% slower than forward.Reference

With 15x19.5 rear tires.Reference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post folding ROPS.Reference

Country of manufacturerCompact Utility tractorReference

Capacities

Capacity80.43 ciReference

Power

Rated Power25.9 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,000 RPMReference

Engine Speed on Rear PTO speed540@2,376 RPMReference

Engine Speed on Mid PTO speed2,000@2,545 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Maximum operating pressure2,200 psiReference

Steering & Implements flow3.2 gpm (7.5 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity1,200.2 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Overall Height207 cmReference

Overall Length308.1 cmReference

Overall Width160 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
