Tractor · 2018Unverified
Mahindra 1626
Mahindra 1626 — Compact Utility tractor · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
2437 to 2459 pounds
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Compact Utility tractorReference
Original price$18,200 (2018 gear )Reference
Original price$23,890 (2018 hydro )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine19.3 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
EmissionsTier IVReference
Power19.3 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Compression22:1Reference
Rated RPM2500Reference
Idle RPM970-2710Reference
StarterelectricReference
Starter volts12Reference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Transmission
8-speed sync shuttleReference
hydrostaticReference
Gear Operating1105 kgReference
Typesync shuttleReference
Gears8 forward and reverseReference
Clutch215mm mechanical dry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)16.0 kWReference
Hydro PTO (claimed)14.2 kWReference
Typeopen centerReference
Pressure151.7 barReference
Pump flow28.4 lpmReference
Steering flow12.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1200 kgReference
Rear lift (at 24"/610mm)780 kgReference
Shuttle Rear PTOliveReference
Hydro Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2376Reference
Mid PTO Type2000 (1.0)Reference
Engine RPM2000@2545Reference
Dimensions
Wheelbase170 cmReference
Weight2437 to 2459 poundsReference
Front tire7-16Reference
Rear tire11.2-24Reference
Weight381 kgReference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Lawn/turf front25x8.5-14Reference
Lawn/turf rear13.6x16Reference
Industrial front27x8.5-15Reference
Industrial rear15x19.5Reference
Length308 cmReference
Width160 cmReference
Height (ROPS)207 cmReference
Ground clearance28 cmReference
Hydro Operating1115 kgReference
Max Drawbar439 kgReference
Mahindra 1626 attachments
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery CCA540Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount MahindraReference
Cutting width182 cmReference
Mahindra 1626B Backhoe
Backhoe typeMahindra 1626B BackhoeReference
Bucket width40 cmReference
Digging depth218 cmReference
2-Foot flat digging depth213 cmReference
Bucket force1106 kgReference
Dipperstick force684 kgReference
Speeds
With 15x19.5 rear tires. Reverse speeds are 15% slower than forward.Reference
With 15x19.5 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
