Tractor · 2018Unverified
Mahindra 1635
Mahindra 1635 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
3075 to 3527 pounds
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Compact Utility tractorReference
Original price was $22,190 in 2019Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
Mahindra 2.0L 3-cyl dieselReference
Fuel tank29.1 LReference
Engine27.0 kWReference
MahindraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke89 x 110 mmReference
EmissionsTier IVReference
Power27.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed sync shuttleReference
hydrostaticReference
Typesync shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Hydro PTO (claimed)19.4 kWReference
Shuttle PTO (claimed)20.6 kWReference
Typeopen centerReference
Pump flow28.4 lpmReference
Total flow40.9 lpmReference
Steering flow12.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1200 kgReference
Shuttle Rear PTOliveReference
Hydro Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2376Reference
Mid PTO Type2000Reference
Engine RPM2000@2526Reference
Dimensions
Wheelbase185 cmReference
Weight3075 to 3527 poundsReference
Front tire7x16Reference
Rear tire11.2x24Reference
Weight381 kgReference
Ag front7x16Reference
Ag rear11.2x24Reference
Lawn/turf front28x8.5-15Reference
Lawn/turf rear43x16-20Reference
Industrial front25x8.5-14Reference
Industrial rear13.6x16Reference
Length314 cmReference
Width160 cmReference
Height (ROPS)229 cmReference
Height (cab)223 cmReference
Ground clearance30 cmReference
Hydro ROPS1394 kgReference
Shuttle ROPS1399 kgReference
Hydro cab1599 kgReference
Mahindra 1635 attachments
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Battery CCA925Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount Mahindra 1672MReference
Cutting width182 cmReference
Mahindra 1635B Backhoe
Backhoe typeMahindra 1635B BackhoeReference
Bucket width40 cmReference
Digging depth218 cmReference
2-Foot flat digging depth213 cmReference
Bucket force1106 kgReference
Dipperstick force684 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
