Tractor · 2018Unverified

Mahindra 1635

Name: Mahindra 1635
Brand: Mahindra

Mahindra 1635 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.

The Mahindra 1635 is a tractor with a rated power output of 26 hp, positioning it towards the lower end of its class. Initially produced in 2018, the tractor features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. Its operating weight ranges from 3075 to 3527 pounds, and it is suited for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

26 hp

Weight

3075 to 3527 pounds

Catalogue coverage

Variants represented

Richest spec table

113 rows

Recorded power

26 hp

Recorded weight

381 kg

Transmissions

8-speed sync shuttle

Production years

2018-1600

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Compact Utility tractorReference

Original price was $22,190 in 2019Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

Mahindra 2.0L 3-cyl dieselReference

Fuel tank29.1 LReference

Engine27.0 kWReference

MahindraReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke89 x 110 mmReference

EmissionsTier IVReference

Power27.0 kWReference

Fuel systemdirect injectionReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,500 RPMReference

Emissions complianceTier IVReference

Bore and stroke3.50x4.33 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speed sync shuttleReference

hydrostaticReference

Typesync shuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeHSTReference

PTO & Hydraulics

Hydro PTO (claimed)19.4 kWReference

Shuttle PTO (claimed)20.6 kWReference

Typeopen centerReference

Pump flow28.4 lpmReference

Total flow40.9 lpmReference

Steering flow12.5 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)1200 kgReference

Shuttle Rear PTOliveReference

Hydro Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2376Reference

Mid PTO Type2000Reference

Engine RPM2000@2526Reference

Dimensions

Wheelbase185 cmReference

Weight3075 to 3527 poundsReference

Front tire7x16Reference

Rear tire11.2x24Reference

Weight381 kgReference

Ag front7x16Reference

Ag rear11.2x24Reference

Lawn/turf front28x8.5-15Reference

Lawn/turf rear43x16-20Reference

Industrial front25x8.5-14Reference

Industrial rear13.6x16Reference

Length314 cmReference

Width160 cmReference

Height (ROPS)229 cmReference

Height (cab)223 cmReference

Ground clearance30 cmReference

Hydro ROPS1394 kgReference

Shuttle ROPS1399 kgReference

Hydro cab1599 kgReference

Mahindra 1635 attachments

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Battery CCA925Reference

Battery volts12Reference

Total cold cranking amps925 CCAReference

Attachment overview

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

72" Mower deck

Typemid-mount Mahindra 1672MReference

Cutting width182 cmReference

Mahindra 1635B Backhoe

Backhoe typeMahindra 1635B BackhoeReference

Bucket width40 cmReference

Digging depth218 cmReference

2-Foot flat digging depth213 cmReference

Bucket force1106 kgReference

Dipperstick force684 kgReference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post folding ROPS.Reference

Country of manufacturerCompact Utility tractorReference

Capacities

Capacity125 ciReference

Power

Rated Power36.2 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 (1.375) RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,000 RPMReference

Engine Speed on Mid PTO speed2,000@2,526 RPMReference

Engine Speed on Rear PTO speed540@2,376 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Steering & Implements flow3.3 gpm (7.5 gpm)Reference

Rear Hitch category (SAE designation)CategoryReference

Rear Hitch maximum lift capacity1,200.2 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over Cab223.5 cmReference

Height Over ROPS229.1 cmReference

Overall Length314.5 cmReference

Overall Width160 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
