Tractor · 2003Unverified
Mahindra 2015
Mahindra 2015 — 15 Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1819 to 1973 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Dry shoe brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.1L 3-cyl dieselReference
Engine14.9 kWReference
Mitsubishi S3LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 79 mmReference
Power14.9 kWReference
Fuel systemindirect injectionReference
Compression22:1Reference
Rated RPM2500Reference
Starter volts12Reference
Transmission
6-speed constant meshReference
hydrostaticReference
Gear Weight825 kgReference
Typeconstant meshReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.0 kWReference
PTO (claimed)11.9 kWReference
Typeopen centerReference
Valves1Reference
Pump flow22.0 lpmReference
Steering flow12.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift635 kgReference
Rear PTOtransmission (gear)Reference
Rear PTOlive (hydro)Reference
Rear PTO Type540Reference
Engine RPM540@2356Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Engine RPM2000@2470Reference
Dimensions
Weight1819 to 1973 poundsReference
Front tire7x15Reference
Rear tire9.5x16Reference
Ag front7x15Reference
Ag rear9.5x16Reference
Lawn/turf front23x8.5-12Reference
Lawn/turf rear33x12.5-16.5Reference
Industrial front23x8.5-12Reference
Industrial rear12x16.5Reference
Length270 cmReference
Width135 cmReference
Hydro Weight894 kgReference
Mahindra 2015 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount MahindraReference
Cutting width152 cmReference
Mahindra 1710C Backhoe
Backhoe typeMahindra 1710C BackhoeReference
Mahindra 2710 Backhoe
Backhoe typeMahindra 2710 BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
