Tractor · 2002Unverified

Mahindra 2310

Name: Mahindra 2310
Brand: Mahindra

Mahindra 2310 — 10 Series · 20 hp. Reference specifications; pending source verification.

The Mahindra 2310 is a tractor with a rated power output of 20 hp, positioned at the lower end of its class in terms of power. It was manufactured from 2002 to 2006. The tractor features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. Its operating weight is listed at 1389 kg, with a suitable operating area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

1389 kg

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

20 hp

Recorded weight

1389 kg

Transmissions

12-speed synchomesh shuttle

Production years

2002-2006

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorMahindraReference

ManufacturerTYMReference

Compact Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Engine

Mahindra 1.3L 3-cyl dieselReference

Engine18.6 kWReference

Mahindra TD1300Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Power18.6 kWReference

Fuel systemindirect injectionReference

Compression21:1Reference

Rated RPM2700Reference

Starter volts12Reference

Transmission

12-speed synchomesh shuttleReference

hydrostaticReference

Gear Length327 cmReference

Typesynchomesh shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)14.9 kWReference

Typeopen centerReference

Gear Pump flow22.3 lpmReference

Hydro Pump flow23.8 lpmReference

Gear Steering flow11.6 lpmReference

Hydro Steering flow17.2 lpmReference

Rear TypeIReference

Controlposition controlReference

Gear Rear lift941 kgReference

Hydro Rear lift943 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540Reference

Engine RPM540@2541 (gear)Reference

Engine RPM540@2775 (hydro)Reference

Mid PTOindependent (hydro only)Reference

Mid PTO Type2000Reference

Engine RPM2000@2650Reference

Dimensions

Weight1389 kgReference

Hydro Length289 cmReference

Width132 cmReference

Mahindra 2310 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Charging volts12Reference

Battery volts12Reference

Battery AH75Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
