Tractor · 2016Unverified
Mahindra 2538
Mahindra 2538 — Compact Utility tractor · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
3130 to 3351 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerTYMReference
Compact Utility tractorReference
Original price$20,790 (2016 ROPS )Reference
Original price$28,220 (2016 Cab )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference
Engine
Mahindra 2.7L 4-cyl dieselReference
Fuel tank34.1 LReference
Engine27.9 kWReference
MahindraReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke89 x 110 mmReference
EmissionsTier IVReference
Power27.9 kWReference
Fuel systemdirect injectionReference
Compression18.7:1Reference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)23.1 kWReference
Typeopen centerReference
Rear valves1 or 2Reference
Pump flow28.8 lpmReference
Steering flow15.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1200 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2400Reference
Dimensions
Weight3130 to 3351 poundsReference
Front tire7-16Reference
Rear tire11.2-24Reference
Weight576 kgReference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Industrial front10-16.5Reference
Industrial rear43x16-20Reference
ROPS Length303 cmReference
Cab Length307 cmReference
Width151 cmReference
Height (ROPS)239 cmReference
Height (cab)234 cmReference
ROPS Weight1419 kgReference
Cab Weight1520 kgReference
Mahindra 2538 attachments
front-end loaderReference
backhoeReference
Electrical
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps90Reference
Charging volts12Reference
Battery CCA800Reference
Battery volts12Reference
Battery AH80Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 2538B Backhoe
Backhoe typeMahindra 2538B BackhoeReference
Transport height302 cmReference
Digging depth238 cmReference
2-Foot flat digging depth233 cmReference
Reach from pivot322 cmReference
Loading height160 cmReference
Bucket Rotation175°Reference
Swing Arc180°Reference
Bucket force1446 kgReference
Dipperstick force898 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
