Tractor · 2016Unverified
Mahindra 2555
Mahindra 2555 — Compact Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
4056 to 4299 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerTYMReference
Compact Utility tractorReference
Original price$27,068 (2016 shuttle ROPS )Reference
Original price$28,553 (2016 hydrostatic ROPS )Reference
Original price$34,493 (2016 shuttle cab )Reference
Original price$35,978 (2016 hydrostatic cab )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning.Reference
Engine
Mahindra 2.6L 3-cyl dieselReference
Fuel tank60.6 LReference
Engine41.0 kWReference
MahindraReference
turbocharged intercooled dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke96 x 122 mmReference
EmissionsTier IVReference
Power41.0 kWReference
Fuel systemdirect injectionReference
Compression17.2:1Reference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed shuttleReference
hydrostaticReference
TypeshuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Shuttle PTO (claimed)33.2 kWReference
Hydro PTO (claimed)31.6 kWReference
Typeopen centerReference
Rear valves1 or 2Reference
Shuttle Pump flow36.0 lpmReference
Hydro Pump flow36.7 lpmReference
Steering flow18.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1503 kgReference
Rear Armstelescopic stabilizersReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2300Reference
Dimensions
Weight4056 to 4299 poundsReference
Front tire9.5x16Reference
Rear tire14.9x24Reference
Weight646 kgReference
Standard tires (ag)Front: 9.5x16. Rear: 14.9x24Reference
Lawn/turf frontLSW305-521Reference
Lawn/turf rearLSW750-648Reference
Industrial front12x16.5Reference
Industrial rear16.9x24Reference
Length340 cmReference
ROPS Width180 cmReference
Cab Width181 cmReference
Height (ROPS)259 cmReference
Height (cab)259 cmReference
ROPS Weight1839 kgReference
Cab Weight1950 kgReference
Mahindra 2555 attachments
front-end loaderReference
backhoeReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 75BL Backhoe
Backhoe typeMahindra 75BL BackhoeReference
Transport height236 cmReference
Digging depth294 cmReference
2-Foot flat digging depth293 cmReference
Reach from pivot388 cmReference
Loading height208 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force2574 kgReference
Dipperstick force2610 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
