Tractor · 2003Unverified
Mahindra 2615
Mahindra 2615 — 15 Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
2315 to 2458 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Engine19.4 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power19.4 kWReference
Compression22:1Reference
Rated RPM2500Reference
Starter volts12Reference
Transmission
9-speed constant meshReference
hydrostaticReference
Gear Weight1050 kgReference
Typeconstant meshReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)17.2 kWReference
PTO (claimed)15.7 kWReference
TypeopencenterReference
Valves1Reference
Pump flow29.5 lpmReference
Steering flow13.2 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift1000 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Engine RPM540@2376Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Engine RPM2000@2632Reference
Dimensions
Weight2315 to 2458 poundsReference
Front tire7x16Reference
Rear tire11.2x24Reference
Ag front7x16Reference
Ag rear11.2x24Reference
Lawn/turf front25x8.5-14Reference
Lawn/turf rear13.6x16Reference
Industrial front27x8.5-15Reference
Industrial rear15x19.5Reference
Length292 cmReference
Width150 cmReference
Hydro Weight1114 kgReference
Mahindra 2615 attachments
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
Charging amps50Reference
Attachment overview
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount MahindraReference
Cutting width182 cmReference
Mahindra 1710B Backhoe
Backhoe typeMahindra 1710B BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
