Tractor · 2008Unverified
Mahindra 2816
Mahindra 2816 — 16 Series · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
2315 to 2458 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Original price was $14,720 in 2009 with hydroReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Folding ROPSReference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Engine20.9 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power20.9 kWReference
Compression22:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speedReference
hydrostaticReference
Gear Operating weight1050 kgReference
Gears9 forward and 3 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Hydro PTO (claimed)15.7 kWReference
Gear PTO (claimed)17.2 kWReference
Typeopen centerReference
Valves0 or 1Reference
Pump flow29.5 lpmReference
Steering flow13.2 lpmReference
Rear TypeIReference
Rear lift (at ends)1000 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Weight2315 to 2458 poundsReference
Front tire7x16Reference
Rear tire11.2x24Reference
Ag front7x16Reference
Ag rear11.2x24Reference
Industrial front27x8.5-15Reference
Industrial rear15x19.5Reference
Length292 cmReference
Width150 cmReference
Hydro Operating weight1114 kgReference
Mahindra 2816 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Battery AH46Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
