Tractor · 2004Unverified
Mahindra 3325
Mahindra 3325 — 25 Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1809 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Built in Maharashtra, IndiaReference
Original price was $10,829 in 2008Reference
Two-wheel driveReference
Steeringmanual recirculating ballReference
Dry disc brakesReference
Two-post folding ROPS.Reference
Engine
Mahindra 1.9L 3-cyl dieselReference
Engine26.1 kWReference
Mahindra MDI1895EReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Power26.1 kWReference
Compression19.4:1Reference
Rated RPM2300Reference
Starter volts12Reference
Transmission
8-speed sliding meshReference
Typesliding meshReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)22.4 kWReference
Typeopen centerReference
Pump flow31.4 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift1598 kgReference
Rear PTOtransmissionReference
Clutchover-runningReference
Rear PTO Type540Reference
Engine RPM540@1980Reference
Dimensions
Weight1809 kgReference
Front tire6x16Reference
Rear tire12.4x28Reference
Ag front6x16Reference
Ag rear12.4x28Reference
Length282 cmReference
Width176 cmReference
3325 Serial Number Location
Serial number plate on the left side of the operator's platform, above the left floor board.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps36Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
