Tractor · 2002Unverified
Mahindra 3510
Mahindra 3510 — 10 Series · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
3064 to 3881 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerTYMReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Mahindra 1.6L 3-cyl dieselReference
Engine25.4 kWReference
Mahindra 3A135Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Power25.4 kWReference
Fuel systemindirect injectionReference
Compression22:1Reference
Rated RPM2700Reference
Starter volts12Reference
Transmission
12-speed synchomesh shuttleReference
hydrostaticReference
Gear Length353 cmReference
Gear Width147 cmReference
Gear Weight1760 kgReference
Typesynchomesh shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)21.4 kWReference
PTO (claimed)20.9 kWReference
Typeopen centerReference
Valves1Reference
Gear Pump flow29.8 lpmReference
Hydro Pump flow24.2 lpmReference
Gear Steering flow13.5 lpmReference
Hydro Steering flow17.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Gear Rear lift1299 kgReference
Hydro Rear lift943 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000 (gear)Reference
Rear PTO Type540 (hydro)Reference
Engine RPM540@2524 (gear)Reference
Engine RPM1000@2866 (gear)Reference
Engine RPM540@2775 (hydro)Reference
Mid PTOindependent (hydro only)Reference
Mid PTO Type2000Reference
Engine RPM2000@2650Reference
Dimensions
Weight3064 to 3881 poundsReference
Hydro Length290 cmReference
Hydro Width132 cmReference
Hydro Weight1389 kgReference
Mahindra 3510 attachments
front-end loaderReference
3510 Serial Number Location
Serial number on front-left of tractor frame.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery volts12Reference
Battery AH110Reference
Attachment overview
Mahindra ML108 loaderReference
Mahindra ML112 loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
