The Mahindra 3525 is a tractor with a rated output of 27 hp, making it a compact option within its class. Produced from 2004 to 2008, this model features a 3-cylinder diesel liquid-cooled engine powering two-wheel drive via a hydrostatic transmission. The listed weight of the Mahindra 3525 is 1989 kg, with an intended application in areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
1989 kg
Catalogue coverage
Variants represented
2
Richest spec table
46 rows
Recorded power
27 hp
Recorded weight
1989 kg
Transmissions
8-speed sliding mesh
Production years
2004-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Built in Maharashtra, IndiaReference
Original price was $12,415 in 2008Reference
Two-wheel driveReference
Steeringhydrostatic powerReference
Dry disc brakesReference
Two-post foldable ROPS.Reference
Engine
Mahindra 1.9L 3-cyl dieselReference
Engine26.1 kWReference
Mahindra MDI1895EReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Power26.1 kWReference
Fuel systemdirect injectionReference
Compression19.4:1Reference
Rated RPM2300Reference
Starter volts12Reference
Transmission
8-speed sliding meshReference
Typesliding meshReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)20.1 kWReference
Typeopen centerReference
Pump flow31.4 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift1598 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Engine RPM540@2058Reference
Dimensions
Weight1989 kgReference
Front tire6x16Reference
Rear tire12.4x28Reference
Ag front6x16Reference
Ag rear12.4x28Reference
Length282 cmReference
Width176 cmReference
Mahindra 3525 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps36Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
