Tractor · 2009Unverified
Mahindra 3535
Mahindra 3535 — 35 Series · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1871 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Compact Utility tractorReference
Built in Maharashtra, IndiaReference
Original price was $19,875 in 2013Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Mahindra 1.9L 3-cyl dieselReference
Engine26.1 kWReference
Mahindra CE35Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
EmissionsTier IVReference
Power26.1 kWReference
Compression19.5:1Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchro shuttle with full synchromeshReference
Typesynchro shuttle with full synchromeshReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)21.6 kWReference
Typeopen centerReference
Rear valves0 to 2Reference
Total flow41.6 lpmReference
Steering flow18.9 lpmReference
Rear TypeIReference
Rear lift1285 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Weight1871 kgReference
Weight458 kgReference
Industrial front28x8.5-15Reference
Industrial rear43x16-20Reference
Length314 cmReference
Width176 cmReference
Operating weight1871 kgReference
Mahindra 3535 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Battery AH96Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 485 Backhoe
Backhoe typeMahindra 485 BackhoeReference
Digging depth256 cmReference
Bucket force1766 kgReference
Dipperstick force1069 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
