Tractor · 2011Unverified
Mahindra 3616
Mahindra 3616 — 16 Series · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
2560 to 3027 pounds
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Original price$19,470 (2013 hydro ROPS )Reference
Original price$18,530 (2013 shuttle ROPS )Reference
Original price$26,690 (2013 hydro cab )Reference
Original price$25,750 (2013 shuttle cab )Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS. Cab optional.Reference
Engine
Mitsubishi 1.7L 3-cyl dieselReference
Fuel tank26.9 LReference
Engine27.0 kWReference
MitsubishiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Power27.0 kWReference
Fuel systemindirect injectionReference
Compression22.5:2Reference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
hydrostaticReference
Gear ROPS Operating1161 kgReference
Gear Cab Operating1369 kgReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)23.1 kWReference
PTO (claimed)21.6 kWReference
Typeopen centerReference
Valves1 (optional)Reference
Pump flow29.1 lpmReference
Steering flow12.9 lpmReference
Rear Type1Reference
Controlposition controlReference
Rear lift1200 kgReference
Rear PTOindependent (gear)Reference
Rear PTOlive (hydro)Reference
Rear PTO Type540Reference
Engine RPM540@2376Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Engine RPM2000@2525Reference
Dimensions
Weight2560 to 3027 poundsReference
Front tire7x16Reference
Rear tire11.2x24Reference
Weight557 kgReference
Weight367 kgReference
Standard tires (ag)Front: 7x16. Rear: 11.2x24Reference
Lawn/turf front27x10.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front28x8.5-15Reference
Industrial rear43x16-20Reference
Length308 cmReference
Width157 cmReference
Height (cab)214 cmReference
Hydro ROPS Operating1163 kgReference
Hydro Cab Operating1373 kgReference
Mahindra 3616 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Batteries12Reference
Battery volts12Reference
Battery AH46Reference
Attachment overview
Front-end loaderReference
BackhoeReference
The model 3716 backhoe is compatible on the 3616 with ROPS while the model MB65 is compatible with cab models.Reference
Mahindra 3716 Backhoe
Backhoe typeMahindra 3716 BackhoeReference
Digging depth238 cmReference
2-Foot flat digging depth233 cmReference
Reach from pivot322 cmReference
Loading height160 cmReference
Bucket Rotation175°Reference
Swing Arc180°Reference
Bucket force1315 kgReference
Dipperstick force816 kgReference
Mahindra MB65 Backhoe
Backhoe typeMahindra MB65 BackhoeReference
Digging depth167 cmReference
2-Foot flat digging depth194 cmReference
Reach from pivot269 cmReference
Loading height157 cmReference
Bucket Rotation180°Reference
Swing Arc150°Reference
Bucket force1149 kgReference
Dipperstick force606 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
