Tractor · 2020Unverified
Mahindra 3640
Mahindra 3640 — Compact Utility tractor · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
498 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab available with air-conditioning.Reference
Engine
Mahindra 2.7L 4-cyl dieselReference
ROPS Fuel tank42.8 LReference
Cab Fuel tank54.9 LReference
Engine29.8 kWReference
MahindraReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke89 x 110 mmReference
Power29.8 kWReference
Fuel systemdirect injectionReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
hydrostaticReference
Typepower shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Hydro PTO (claimed)22.7 kWReference
Gear PTO (claimed)23.1 kWReference
Typeopen centerReference
Rear valves1Reference
Pump flow41.6 lpmReference
Total flow60.6 lpmReference
Rear TypeII/IReference
Rear lift1401 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2405Reference
Dimensions
Wheelbase190 cmReference
Weight498 kgReference
Length327 cmReference
Height (ROPS)250 cmReference
Height (cab)254 cmReference
Ground clearance34 cmReference
Mahindra 3640 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps90Reference
Charging volts12Reference
Battery CCA925Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 65B Backhoe
Backhoe typeMahindra 65B BackhoeReference
Bucket width45 cmReference
Digging depth284 cmReference
2-Foot flat digging depth279 cmReference
Bucket force1766 kgReference
Dipperstick force1069 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
