Tractor · 2008Unverified
Mahindra 3825
Mahindra 3825 — 25 Series · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1851 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Built in Maharashtra, IndiaReference
Original price$11869 (2008 )Reference
Original price$11,869 (2009 )Reference
Two-wheel driveReference
Steeringmanual recirculating ballReference
Dry disc brakesReference
Two-post folding ROPSReference
Engine
Mahindra 2.7L 4-cyl dieselReference
Engine30.6 kWReference
Mahindra MDI 2700R2Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke89 x 110 mmReference
Power30.6 kWReference
Fuel systemdirect injectionReference
Compression19.5:1Reference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed sliding meshReference
Typesliding meshReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)23.9 kWReference
Typeopen centerReference
Valves0 or 1Reference
Total flow31.4 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)1599 kgReference
Rear PTOtransmissionReference
Clutchover-runningReference
Rear PTO Type540Reference
Engine RPM540@1980Reference
Dimensions
Weight1851 kgReference
Front tire6x16Reference
Rear tire12.4x28Reference
Ag front6x16Reference
Ag rear12.4x28Reference
Length292 cmReference
Width176 cmReference
Operating weight1851 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps36Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
