The Mahindra 4505 is a tractor with a rated power output of 35 hp, categorising it at the lighter end of its class. It was manufactured from 1999 to 2002. The tractor is equipped with a 4-cylinder diesel liquid-cooled engine, paired with two-wheel drive and an 8-speed gearbox. Its operating weight is listed at 1846 kg, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1846 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
35 hp
Recorded weight
1846 kg
Transmissions
8-speed gear
Production years
1999-2002
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Built in Maharashtra, IndiaReference
Two-wheel driveReference
Power steeringReference
Dry disc brakesReference
Two-post fixed ROPS.Reference
Engine
Mahindra 2.5L 4-cyl dieselReference
Engine32.1 kWReference
Mahindra MDI 2500Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke89 x 102 mmReference
Power32.1 kWReference
Fuel systemdirect injectionReference
Compression18:1Reference
Rated RPM2300Reference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)25.7 kWReference
Typeopen centerReference
Valves1Reference
Pump flow31.4 lpmReference
Rear TypeII/IReference
Rear lift1598 kgReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Engine RPM540@2058Reference
Engine RPM1000@2043Reference
Dimensions
Weight1846 kgReference
Front tire6x16Reference
Rear tire13.6x28Reference
Ag front6x16Reference
Ag rear13.6x28Reference
Length331 cmReference
Ground clearance33 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps36Reference
Battery volts12Reference
Battery AH88Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
