Tractor · 2004Unverified
Mahindra 4510
Mahindra 4510 — 10 Series · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Weight
2148 kg
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerTYMReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockstandardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard with heat and air-conditioning.Reference
Engine
Daedong 2.2L 4-cyl dieselReference
Engine33.6 kWReference
DaedongReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Power33.6 kWReference
Fuel systemindirect injectionReference
Compression22:1Reference
Rated RPM2500Reference
Starter volts12Reference
Transmission
16-speed synchro shuttleReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)26.8 kWReference
Typeopen centerReference
Valves3Reference
Pump flow36.3 lpmReference
Steering flow16.3 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift1300 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540Reference
Engine RPM540@2391Reference
Dimensions
Weight2148 kgReference
Front tire9.5x16Reference
Rear tire16.9x24Reference
Ag front9.5x16Reference
Ag rear16.9x24Reference
Industrial front12x16.5Reference
Industrial rear16.9x24Reference
Length367 cmReference
Width162 cmReference
Mahindra 4510 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery volts12Reference
Battery AH110Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
