Tractor · 2014Unverified

Mahindra 4540

Name: Mahindra 4540
Brand: Mahindra

Mahindra 4540 — Utility tractor · 31 hp. Reference specifications; pending source verification.

The Mahindra 4540 is a compact tractor model, rated at 31 hp. It was introduced in 2014. The 4540 is powered by a 4-cylinder diesel liquid-cooled engine, which drives four-wheel drive through an 8-speed gearbox. It has a listed weight of 4191 to 5192 pounds and is suited for tasks of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

31 hp

Weight

4191 to 5192 pounds

Catalogue coverage

Variants represented

Richest spec table

105 rows

Recorded power

31 hp

Recorded weight

1901 kg

Transmissions

8-speed gear

Production years

2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Utility tractorReference

Original price$17,955 (2016 2WD )Reference

Original price$23,288 (2016 4WD )Reference

Two- or four-wheel driveReference

Power steeringReference

Dry disc brakesReference

Two-post foldable ROPS.Reference

Engine

Mahindra 2.7L 4-cyl dieselReference

Fuel tank55.3 LReference

Engine30.6 kWReference

MahindraReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.7 LReference

Bore/Stroke89 x 110 mmReference

EmissionsTier IVReference

Power30.6 kWReference

Fuel systemdirect injectionReference

Compression18.7:1Reference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4 cylinderReference

Rated engine speedOption 1: 2,300\\nOption 2: 2,300 RPMReference

Emissions complianceTier IVReference

Bore and stroke3.50x4.33 inchesReference

Compression ratio18.7:1Reference

Cooling systemwater-cooledReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutchdry discReference

Transmission TypeGearReference

forward and reverse options8 F and 2 RReference

PTO & Hydraulics

PTO (claimed)23.1 kWReference

Typeopen centerReference

Rear valves1Reference

Pump flow32.9 lpmReference

Steering flow22.0 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

2WD Rear lift1598 kgReference

4WD Rear lift1599 kgReference

Rear PTOliveReference

Clutchdual-stage clutchReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2058Reference

Dimensions

Weight4191 to 5192 poundsReference

Front tire6x16Reference

2WD Rear tire12.4x28Reference

2WD Standard tires (ag)Front: 6x16. Rear: 12.4x28Reference

4WD Standard tires (ag)Front: 9.5x16. Rear: 12.4x28Reference

Industrial front12.6x16.5Reference

Industrial rear16.9x24Reference

2WD Length292 cmReference

4WD Length327 cmReference

2WD Width176 cmReference

4WD Width209 cmReference

2WD Height (ROPS)223 cmReference

4WD Height (ROPS)235 cmReference

2WD Weight1901 kgReference

4WD Weight2355 kgReference

Mahindra 4540 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Mahindra 4550-2L loaderReference

Mahindra 4550-4L loaderReference

BackhoeReference

Mahindra 4550B Backhoe

Backhoe typeMahindra 4550B BackhoeReference

Digging depth256 cmReference

2-Foot flat digging depth255 cmReference

Reach from pivot342 cmReference

Loading height226 cmReference

Bucket Rotation155°Reference

Swing Arc180°Reference

Bucket force1664 kgReference

Dipperstick force1047 kgReference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post foldable ROPSReference

Country of manufacturerUtility tractorReference

Capacities

Capacity167 ciReference

Power

Rated Power41 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540 @ 2,058 RPMReference

Steering & brakes

BrakesFully enclosed dry discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1 valvesReference

Number of rear selective control valves (SCVs)1Reference

Steering & Implements flow5.8 gpm (8.7 gpm)Reference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch maximum lift capacity1,599.8 kgReference

Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Overall Height235.2 cmReference

Overall Length327.4 cmReference

Overall Width209.8 cmReference

Turning radius10.5 feet (without Brakes)Reference

Wheels & tyres

Rear Wheel TypeAg rear - 12.4x28Reference

Front Wheel TypeAg front - 9.5x16Reference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
