Tractor · 2014Unverified

Mahindra 4565

Name: Mahindra 4565
Brand: Mahindra

Mahindra 4565 — Utility tractor · 52 hp. Reference specifications; pending source verification.

The Mahindra 4565 is a tractor model with a rated power of 52 hp, positioning it at the lighter end of its class. This model entered production in 2014 and features a 3-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with two-wheel drive and an 8-speed gearbox. The operating weight of the Mahindra 4565 is listed as 2215 kg, with a suitable operating area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

52 hp

Weight

2215 kg

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

52 hp

Recorded weight

2215 kg

Transmissions

8-speed constant mesh

Production years

2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Utility tractorReference

Original price was $22,680 in 2015Reference

Two-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Dry disc brakesReference

Two-post foldable ROPS.Reference

Engine

2.6L 3-cyl dieselReference

Engine46.2 kWReference

VNE 360Reference

turbocharged intercooled dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.6 LReference

Bore/Stroke96 x 122 mmReference

EmissionsTier IVReference

Power46.2 kWReference

Fuel systemcommon rail direct injectionReference

Air cleanerdryReference

Compression17.2:1Reference

Rated RPM2100Reference

Idle RPM850-2300Reference

Firing order1-3-2Reference

StarterelectricReference

Starter volts12Reference

Oil capacity8.8 LReference

Coolant capacity8.5 LReference

Transmission

8-speed constant meshReference

Typeconstant meshReference

Gears8 forward and 2 reverseReference

Clutch279.4mm dry discReference

PTO & Hydraulics

PTO (claimed)38.8 kWReference

Hydraulic system35.2 LReference

Typeopen centerReference

Capacity35.2 LReference

Pressure165.5 barReference

Valves1 or 2Reference

Pump flow39.7 lpmReference

Total flow57.9 lpmReference

Steering flow18.2 lpmReference

Rear TypeIIReference

Controlposition controlReference

Rear lift (at ends)1599 kgReference

Rear lift (at 24"/610mm)948 kgReference

Rear Armstelescopic stabilizersReference

Rear PTOcontinuousReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2059Reference

Capacities

Fuel56.0 LReference

Dimensions

Wheelbase194 cmReference

Weight2215 kgReference

Front tire7.5x16Reference

Rear tire14.9x28Reference

Ag front7.5x16Reference

Ag rear14.9x28Reference

Length302 cmReference

Width198 cmReference

Height162 cmReference

Height (ROPS)241 cmReference

Ground clearance36 cmReference

Front tread133 to 173 cmReference

Rear tread152 to 182 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Charging volts12Reference

Battery volts12Reference

Battery AH96Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
