Tractor · 2014Unverified
Mahindra 4565
Mahindra 4565 — Utility tractor · 52 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
2215 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Original price was $22,680 in 2015Reference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Dry disc brakesReference
Two-post foldable ROPS.Reference
Engine
2.6L 3-cyl dieselReference
Engine46.2 kWReference
VNE 360Reference
turbocharged intercooled dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke96 x 122 mmReference
EmissionsTier IVReference
Power46.2 kWReference
Fuel systemcommon rail direct injectionReference
Air cleanerdryReference
Compression17.2:1Reference
Rated RPM2100Reference
Idle RPM850-2300Reference
Firing order1-3-2Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.8 LReference
Coolant capacity8.5 LReference
Transmission
8-speed constant meshReference
Typeconstant meshReference
Gears8 forward and 2 reverseReference
Clutch279.4mm dry discReference
PTO & Hydraulics
PTO (claimed)38.8 kWReference
Hydraulic system35.2 LReference
Typeopen centerReference
Capacity35.2 LReference
Pressure165.5 barReference
Valves1 or 2Reference
Pump flow39.7 lpmReference
Total flow57.9 lpmReference
Steering flow18.2 lpmReference
Rear TypeIIReference
Controlposition controlReference
Rear lift (at ends)1599 kgReference
Rear lift (at 24"/610mm)948 kgReference
Rear Armstelescopic stabilizersReference
Rear PTOcontinuousReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2059Reference
Capacities
Fuel56.0 LReference
Dimensions
Wheelbase194 cmReference
Weight2215 kgReference
Front tire7.5x16Reference
Rear tire14.9x28Reference
Ag front7.5x16Reference
Ag rear14.9x28Reference
Length302 cmReference
Width198 cmReference
Height162 cmReference
Height (ROPS)241 cmReference
Ground clearance36 cmReference
Front tread133 to 173 cmReference
Rear tread152 to 182 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
