Mahindra 475 DI
Mahindra 475 DI — Yuvo Series · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Weight
2019 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Two-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Wet disc brakesReference
Open operator station.Reference
Engine
Mahindra 2.7L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine31.3 kWReference
MahindraReference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.7 LReference
Bore/Stroke89 x 110 mmReference
Power31.3 kWReference
Air cleanerdryReference
Rated RPM2000Reference
Torque168.4 NmReference
Starter typeelectricReference
Transmission
12-speed constant meshReference
Typeconstant meshReference
Gears12 forward and 3 reverseReference
Clutchdry discReference
Four gears (1-4), plus reverse (R))in three ranges.Reference
PTO & Hydraulics
PTO (claimed)28.7 kWReference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTO Type540Reference
Engine RPM23.76Reference
Dimensions
Wheelbase192 cmReference
Weight2019 kgReference
Front tire6x16Reference
Rear tire13.6x28Reference
Ag front6x16Reference
Ag rear13.6x28Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
