Tractor · 2021Unverified

Mahindra 5155

Name: Mahindra 5155
Brand: Mahindra

Mahindra 5155 — Compact Utility tractor · 47 hp. Reference specifications; pending source verification.

The Mahindra 5155 is a compact tractor model with a rated output of 47 hp. Introduced in 2021, it features a 4-cylinder turbocharged diesel liquid-cooled engine, which drives the four-wheel drive system through a 12-speed gearbox. The 5155 has a listed weight of 2444 kg and is designed for use in jobs covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

2444 kg

Catalogue coverage

Variants represented

Richest spec table

84 rows

Recorded power

47 hp

Recorded weight

2444 kg

Transmissions

12-speed sync shuttle

Production years

2021

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Compact Utility tractorReference

Original price was $31,443 in 2023Reference

Four-wheel driveReference

Power steeringReference

Wet disc ((Sales literature indicates dry disc brakes, the manuals indicate wet disc.)) brakesReference

Two-post folding ROPS.Reference

Engine

Mahindra 2.7L 4-cyl dieselReference

Fuel tank64.7 LReference

Engine41.0 kWReference

MahindraReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.7 LReference

Bore/Stroke89 x 110 mmReference

Power41.0 kWReference

Fuel systemdirect injectionReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4-cylinderReference

Rated engine speedOption 1: 2,300\\nOption 2: 2,300 RPMReference

Bore and stroke3.50x4.33 inchesReference

Cooling systemliquid-cooledReference

Transmission

12-speed sync shuttleReference

Typesync shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

forward and reverse options12 forward and reverseReference

PTO & Hydraulics

PTO (claimed)35.0 kWReference

Typeopen centerReference

Pump flow33.0 lpmReference

Steering flow17.5 lpmReference

Rear TypeII/IReference

Controlposition controlReference

Rear lift1700 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2300Reference

Engine RPM540E@1725Reference

Dimensions

Wheelbase197 cmReference

Weight2444 kgReference

Front tire9.5-20Reference

Rear tire14.9-28Reference

Weight498 kgReference

Standard tires (ag)Front: 9.5-20. Rear: 14.9-28Reference

Industrial front10.5/80-18Reference

Industrial rear16.9-24Reference

Length346 cmReference

Width189 cmReference

Height153 cmReference

Ground clearance41 cmReference

Mahindra 5155 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Charging volts12Reference

Battery CCA925Reference

Battery volts12Reference

Total cold cranking amps925Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Mahindra 65B Backhoe

Backhoe typeMahindra 65B BackhoeReference

Bucket width45 cmReference

Digging depth284 cmReference

2-Foot flat digging depth279 cmReference

Bucket force1766 kgReference

Dipperstick force1069 kgReference

General

Make & ModelMahindraReference

Capacities

Capacity166.7 ciReference

Power

Rated Power55 hpReference

PTO

Measuring Protocol for PTO Power@2,300, 540E@1,725Reference

Rear PTO PowerAvailableReference

Hydraulics

Hydraulics Typeopen centerReference

Steering & Implements flow4.62 gpm (8.71 gpm)Reference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch maximum lift capacity1,700.1 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Overall Height153.9 cmReference

Overall Length347 cmReference

Overall Width190 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
