Tractor · 2008Unverified
Mahindra 5520
Mahindra 5520 — 20 Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
6057 to 6422 pounds
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Built in Maharashtra, IndiaReference
Original price$21,190 (2008 2WD )Reference
Original price$24,180 (2008 4WD )Reference
The 509 backhoe was compatible with the Mahindra 5520 with four-wheel drive.Reference
Two- or four-wheel driveReference
Differential lockstandardReference
Power steeringReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
3.4L 4-cyl dieselReference
Engine41.0 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Power41.0 kWReference
Fuel systemdirect injectionReference
Compression19.4:1Reference
Rated RPM2100Reference
Starter volts12Reference
Transmission
12-speed sync shuttleReference
Typesync shuttleReference
Gears12 forward and reverseReference
Clutchdual dry with cerametallic liningReference
PTO & Hydraulics
PTO (claimed)33.6 kWReference
TypeOpen centerReference
Valves1Reference
Pump flow41.6 lpmReference
Steering flow16.7 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift2313 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@1978Reference
Dimensions
Weight6057 to 6422 poundsReference
Front tire7.5x16Reference
2WD Rear tire14.9x28Reference
Weight646 kgReference
2WD Standard tires (ag)Front: 7.5x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 9.5Lx20. Rear: 14.9x28Reference
Industrial front12x16.5 (4WD)Reference
Industrial rear17.5x24 (4WD)Reference
Length367 cmReference
Width195 cmReference
2WD Weight2747 kgReference
4WD Weight2913 kgReference
Mahindra 5520 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 509 Backhoe
Backhoe typeMahindra 509 BackhoeReference
Digging depth294 cmReference
2-Foot flat digging depth292 cmReference
8-Foot flat digging depth251 cmReference
Reach from pivot388 cmReference
Loading height208 cmReference
Swing Arc180°Reference
Bucket force2574 kgReference
Dipperstick force1249 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
