Tractor · 2015Unverified
Mahindra 5545
Mahindra 5545 — Utility tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2525 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Original price was $28,140 in 2016Reference
Four-wheel driveReference
Power steeringReference
Dry disc brakesReference
Two-post foldable ROPS.Reference
Engine
Mahindra 2.7L 3-cyl dieselReference
Fuel tank45.4 LReference
Engine32.1 kWReference
MahindraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke96 x 122 mmReference
EmissionsTier IVReference
Power32.1 kWReference
Fuel systemdirect injectionReference
Compression17.5:1Reference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed sync shuttleReference
Typesync shuttleReference
Gears8 forward and reverseReference
Clutchcerametallic dry discReference
PTO & Hydraulics
PTO (claimed)26.0 kWReference
Typeopen centerReference
Rear valves1Reference
Pump flow41.3 lpmReference
Steering flow18.9 lpmReference
Rear TypeII/IReference
Controlposition and draftcontrolReference
Rear lift1800 kgReference
Rear Armstelescopic stabilizersReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2058Reference
Dimensions
Weight2525 kgReference
Front tire9.5x20Reference
Rear tire13.6x28Reference
Weight852 kgReference
Weight929 kgReference
Standard tires (ag)Front: 9.5x20. Rear: 13.6x28Reference
Industrial front10.5/80x18Reference
Industrial rear16.9x24Reference
Length340 cmReference
Width184 cmReference
Height (ROPS)236 cmReference
Mahindra 5545 attachments
front-end loaderReference
backhoeReference
Electrical
Charging systemalternatorReference
Charging amps45Reference
Charging volts12Reference
Battery volts12Reference
Battery AH96Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Mahindra 75B Backhoe
Backhoe typeMahindra 75B BackhoeReference
Transport height236 cmReference
Digging depth294 cmReference
2-Foot flat digging depth292 cmReference
Reach from pivot388 cmReference
Loading height208 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force2574 kgReference
Dipperstick force1249 kgReference
Mahindra 85B Backhoe
Backhoe typeMahindra 85B BackhoeReference
Transport height269 cmReference
Digging depth337 cmReference
2-Foot flat digging depth335 cmReference
Reach from pivot439 cmReference
Loading height243 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force2574 kgReference
Dipperstick force1386 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
